25A Solar DC circuit breaker 2P
Sold by
@ MODERN HALLROAD Ask ownerMODERN HALLROAD
Miniature circuit breakers for solar generation non polarized circuit breaker with TUV certificate
Application
Introduction:
JB DC miniature circuit breaker is designed to protect the cables located between each string of photo-voltaic modules and the photo-voltaic inverter against overloads and short circuits (see application diagram). Combined with a switch, will be installed in a string PV protection enclosure at the end of each string of photo-voltaic modules. It can be locked (by a padlocking device) in OFF position as a safety measure for removal of the PV inverter. Since a fault current can flow in the reverse direction to the operating current, can detect and protect against any bidirectional current.
₨ 1,450.00
Product Detail:
| Model No: | C65 mcb |
| Rated Current: | 1A~32A |
| Rated Voltage: | 230Vac(1P), 400Vac(2P) |
| Characteristic Curve: | B, C, D |
| No. of Pole: | 2p |
| Breaking Capacity: | 6000A (M type) |
| 10000A (H type) | |
| Standards: | IEC60898 IEC-60947-2 |
| Certificates: | CE |
