5V 20A Power Supply 100W AC to DC Switching Power Supply

5V 20A Power Supply 100W AC to DC Switching Power Supply is AC to DC Power Supply which is suitable for PLC, MICROCONTROLLER, CNC etc.

This 5V 20A Power Supply 100W AC to DC Switching Power Supply is very reliable for industrial and domestic use. 5V DC, 100W switching power supply can convert full range AC (selected by switch) to DC, current rating to 10A.

Cheap and reliable SMPS power supply for wide applications like LED lamps, security cameras, communications equipment, industrial control, and household appliances.

input Voltage 200-240 volt Output Voltage- DC 5V 20A Power- 100W DC Switching Switch Power Supply For Neopixel Led Light, WS2812B LED Strip, CCTV, etc.

A switched-mode power supply (SMPS) is an electronic circuit that converts power using switching devices that are turned on and off at high frequencies, and storage components such as inductors or capacitors to supply power when the switching device is in its non-conduction state.

Design with Built-in EMI Filter, Improve Signal Precision., Power LED Monitor (LED Glow when in Use), Category – Switch Mode Power Adaptor (SMPS), IN-DOOR USE ONLY!,

This Power Supply Unit “DOES NOT” comes with an installation instruction, wiring cable, on/off switch, or screws. The professional installation of qualified electricians is highly recommended.

Features:

1. DC Voltage: 5V
2. Rated Current: 20A
3. Current Range: 0-20.5A
4. Rated Power: 100W
5. Ripple & Noise (maximun): 150mV
6. Voltage Tolerance: +/- 2.0%
7. Line Regulation: +/- 0.5%
8. Load Regulation: +/- 0.5%
9. Setup, Rise, Hold Up Time: 200ms, 100ms, 50ms, at full load
10. Voltage Range:  180-264V AC by
11. Frequency Range: 47-63HZ
12. Efficiency:  85%
13. Inrush Current: 13A/115V 25A/230V
14. Leakage Current: <1mA/240VAC
15. Working Temp. :  -20℃~60℃
16. Working Humidity : 20%-90% RH

Package:-

1 x 5V-20A Power Supply
