LM358 IC Low-Power Single Supply Dual Operational Amplifier

Sold by
sherjaan
@ sherjaan

This LM358P IC is a dual op-amp IC integrated with two op-amps powered by a common power supply. LM358P can consider as one half of LM324 Quad op-amp which contains four op-amps with common power supply.

 20.00

In stock

LM358 IC is Low-Power Single Supply Dual Operational Amplifier consists of two independent, high gain, internally frequency compensated operational amplifiers which were designed specifically to operate from a single power supply over a wide range of voltages.

Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage.

Application areas include transducer amplifiers, dc gain blocks and all the conventional op amp circuits which now can be more easily implemented in single power supply systems.

LM358 IC is a dual op-amp IC integrated with two op-amps powered by a common power supply. It can be considered as one half of LM324 Quad op-amp which contains four op-amps with common power supply.

The differential input voltage range can be equal to that of power supply voltage. The default input offset voltage is very low which is of magnitude 2mV. The typical supply current is 500uA independent of the supply voltage range and a maximum current of 700uA. The operating temperature ranges from 0˚C to 70˚C at ambient whereas the maximum junction temperature can be up to 150˚C.

The LM358 IC op amp belongs to a sort of low power dual operational amplifiers, consisted of two independent, high gain, internally frequency compensated operational amplifiers, which were designed specifically to operate from a single power supply over a wide range of voltage.

The LM358 IC amplifier can operate at supply voltages as low as 3.0 V or as high as 32 V. The common mode input range includes the negative supply, thereby eliminating the necessity for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.

Features: –

  • Low power operation of 0.7mA
  • Operates from a single positive power supply of 3 to 32V
  • Can also operate from a split supply of ± 1.5 to ±16V like typical Op-Amp
  • 700kHz unity gain bandwidth
  • Open loop gain of 100x

LM358 IC Specifications: –

  • Internally frequency compensated for unity gain
  • Large dc voltage gain: 100 dB
  • Very low supply current drain (500μA); essentially independent of supply voltage
  • Wide bandwidth (unity gain): 1MHz (temperature compensated)
  • Input common-mode voltage range includes ground
  • Differential input voltage range equal to the power supply voltage
  • Low input offset voltage: 2mV
  • Wide power supply range: o Single supply: 3V to 32V o Dual supplies: ±1.5V to ±16V
  • Large output voltage swing: 0V to V+ – 1.5V
  • SOP-8L packaging
  • Green” Molding Compound (No Br, Sb)
  • Lead Free Finish/ RoHS Compliant (Note 1)

LM358 IC Applications: –

  • Eliminates the need for dual supplies
  • Compatible with all forms of logic
  • Two internally compensated op amps
  • Low power drain ideal for battery operation
  • Allows direct sensing near GND
  • VOUT can swing to GND
  • Transducer Amplifiers
  • Conventional op-amp circuits
  • Integrator, Differentiator, Summer, adder, Voltage follower, etc.,
  • DC gain blocks, Digital multimeters, Oscilloscopes
  • Comparators (Loop control & regulation)
LM358 IC Datasheet: –

diodes.com/assets/Datasheets/LM358.pdf

Package:-

1 x LM358 IC Low-Power Single Supply Dual Operational Amplifier
