CA3130 CMOS Op-Amp IC 15MHz BiMOS Operational Amplifier

@ MODERN HALLROAD

CA3130 CMOS Op-Amp IC is op amps that combine the advantage of both CMOS and bipolar transistors. Gate-protected P-Channel MOSFET (PMOS) transistors are used in the input circuit to provide very-high-input impedance, very-low-input current, and exceptional speed performance.

 180.00

In stock

SKU: CA3130 Category: Tag:

CA3130 CMOS Op-Amp IC is op amps that combine the advantage of both CMOS and bipolar transistors.

Gate-protected P-Channel MOSFET (PMOS) transistors are used in the input circuit to provide very-high-input impedance, very-low-input current, and exceptional speed performance.

CA3130 CMOS Op-Amp IC Series circuits operate at supply voltages ranging from 5V to 16V, (2.5V to 8V).

They can be phase compensated with a single external capacitor, and have terminals for adjustment of offset voltage for applications requiring offset-null capability. Terminal provisions are also made to permit strobing of the output stage.

The CA3130A offers superior input characteristics over those of the CA3130.

CA3130 is a BiMOS operational amplifier IC with MOSFET Input and BiMOS devices have advantages of both bipolar and CMOS transistors.

Bipolar transistors can perform fast switching and perform well under high bandwidths. On the other hand, CMOS op-amps consume less current.

The CA3130 consists of PMOS transistors at the input and CMOS transistors at the output.

These transistors provide the advantages of high impedance, high speed, less current consumption, and high bandwidth. It has a multitude of applications.

What is an Operational Amplifier (Op-amp) An operational amplifier is an integrated circuit that can amplify weak electric signals.

An operational amplifier has two input pins and one output pin. Its basic role is to amplify and output the voltage difference between the two input pins.

Specifications: –

  • Op-amp coupled with MOSFET at output
  • Wide power supply Range
  • Singe supply – 5V to 16V
  • Dual supply – ±2.5V to ±8V
  • Maximum Output Voltage: 13.3V
  • Maximum source current: 22mA
  • Input Terminal current: 1mA
  • Maximum sink current: 20mA
  • Supply current: 10mA
  • Common Mode Rejection Ration (CMRR): 80dB

CA3130 CMOS Op-Amp IC Applications: –

  • Frequency Generator/Distorter
  • Mobile jammers
  • Voltage follower circuits
  • DAC circuits
  • Peak Signal/Noise detectors
  • Oscillator circuits

CA3130 CMOS Op-Amp IC Pin Configuration

Number Pin Name Description
1,5 Offset Null Pins Optionally used to remove the offset voltage at the output pin to make it perfect 0V during off state.
2 Inverting Input (IN-) The Inverting pin is also given a fixed voltage which is compared with the (IN+)
3 Non-Inverting Input (IN+) The Non-Inverting Pin of the comparator is give a variable  voltage to compare
4 Ground (VCC-) This pin is connected to the ground of the system (Negative voltage can also be used)
6 Output This is the output pin of the op-amp
7 VCC+ Provide the operating voltage for the Op-Amp. For CA3130 it is upto +16V
8 Strobe Allows you to turn off output stage
Datasheet: –

renesas.com/…dst/ca3130-ca3130a-datasheet

Package: –

1 x CA3130 Operational Amplifier IC, 15MHz
