JHD12864E Graphic LCD 128X64 – Blue Color LCD

The JHD12864E is a 128X64 monochrome graphic LCD display module with a blue backlight. 128X64 Blue Color LCD is a STN-type LCD with a simple command interface. The display can operate in both parallel and serial (SPI) modes. In SPI mode, only 3 data pins are required to drive the display.

128X64 JHD12864 LCD is a popular choice for embedded applications, such as 3D printers, industrial control panels, and home automation devices. It is also a good choice for educational projects and prototyping.

The JHD12864E 128X64 graphic LCD has an input voltage of 5V. The recommended LCD driving voltage for normal temperature version module @25ºC is 8V. It is important to note that the backlight current is also 5V, so you will need a power supply that can provide at least 5V and 100mA.

The JHD12864E 128X64 is a positive transflective graphic LCD, which means that it can be viewed in both ambient light and with the backlight on. The transflective display works by reflecting light back from the front of the LCD and the back of the LCD. This allows the display to be seen in both bright and dark environments.

The JHD12864E can interface in two ways: 8-bit parallel and SPI. In 8-bit parallel mode, the display connect to 8 data pins, 3 control pins, and a backlight pin. The data pins are used to send the pixel data to the display.

In SPI mode, the display is connect to 3 data pins, a clock pin, and a chip select pin. The data pins use to send the pixel data to the display. The clock pin use to synchronize the data transfer. The chip select pin use to select the display.

Features : –

The JHD12864 COB (Chip On Board) is a type of JHD12864E graphic LCD that has the controller IC or driver directly mounted on the back of the PCB. This means that the display is a single, integrated unit, which can make it easier to assemble and use.

The JHD12864 is a popular choice for embedded applications, such as 3D printers, industrial control panels, and home automation devices. It is also a good choice for educational projects and prototyping. The JHD12864 graphic LCD has a number of benefits that make it a popular choice for a variety of applications. These benefits include:

• 128X64 pixel resolution: The JHD12864 LCD has a high-resolution display that can use to display text, images, and graphics.
• Blue backlight: The JHD12864 LCD has a blue backlight that makes the display easy to read in both bright and dark environments.
• STN-type LCD: The JHD12864 LCD is an STN-type LCD, which means that it has a relatively fast response time. This makes it suitable for applications where fast graphics updates required.
• Simple command interface: The JHD12864 LCD has a simple command interface that makes it easy to control the display.
• Low power consumption: The JHD12864 LCD consumes a relatively low amount of power, making it suitable for battery-powered applications.
• Cost-effective: The JHD12864 LCD is a cost-effective graphic LCD that is a good choice for a variety of applications.

JHD12864E Graphic LCD 128X64 Specifications : –

This 128×64 is a versatile and affordable graphic LCD that is well-suited for a wide range of applications. It is easy to interface with and it is relatively easy to find. If you are looking for a graphic LCD for your next project, the 128X64 is a good option to consider.

The JHD 128X64 graphic LCD has the following specifications:

• Display resolution: 128X64 pixels
• Display type: STN-type LCD
• Backlight color: Blue
• Interface: 8-bit parallel or SPI
• Operating voltage: 3.3V
• Current consumption: 100mA
• Dimensions: 65.5x38x12mm
• Weight: 25g

JHD12864E Graphic LCD 128X64 Pin Descriptions : –

The JHD 128X64E graphic LCD has 20 pins, which are divided into three groups: power pins, control pins, and data pins.

Power pins:

• VDD: This pin is the power supply pin for the display. It should connect to a 3.3V power supply.
• VSS: This pin is the ground pin for the display. It should connect to a common ground.
• VLCD: This pin is the voltage for the liquid crystal display. It should be connected to a voltage between 2.6V and 18V.

Control pins:

• RS: This pin is the register select pin. It is use to select the register that will be accessed.
• RW: This pin is the read/write pin. It is use to select whether the display will read or writte to.
• E: This pin is the enable pin. It is use to enable the display.
• BL: This pin is the backlight pin. It is use to turn the backlight on or off.

Data pins:

• D0-D7: These pins are the data pins. They are use to send the pixel data to the display.

JHD12864E Graphic LCD 128X64 Applications : –

The JHD12864E graphic LCD is a versatile and affordable display that well-suited for a wide range of applications. Here are some of the specific applications where the JHD12864E graphic LCD commonly used:

• 3D printers
• Industrial control panels
• Home automation devices
• Educational projects
• Point of sale (POS) systems
• Digital signage
• Machine vision

Package : –

1 x JHD12864E Graphic LCD 128X64
