Name: 200KG Capacity Strain Gauge Load Cell
SKU: 18579
Price: 6500.00 PKR
Availability: OutOfStock

This is 200KG Capacity Strain Gauge Load Cell Load Sensor Compatible with Arduino, Microchip and other development boards. A load cell is a transducer that is used to create an electrical signal whose magnitude is directly proportional to the force being measured. The various types of load cells include hydraulic load cells, pneumatic load cells and strain gauge load cells.

The 200KG Capacity Strain Gauge Load Cell elastic body was shear or bending of cantilever beam structure, one end fixed, one end bearing, shape of low height, high strength structure, it can be used for a variety of tensile and compressive force bearing and the measurement. It has: dustproof sealing, wide capacity, high precision, stable and reliable performance, it is convenient to install and use. Apply to electronic scale, weighing apparatus etc. ,such as weighing the various measuring, weighing industrial automation measurement and control system.

This is a standard load cell for measuring weight up to 200 Kg. The most common use of this sensor is in weighing machine. Every weighing machine which shows weight has a loadcell as sensing element.

The electrical signal output is typically in the order of a few millivolts and requires amplification by an instrumentation amplifier before it can be used. The output of the transducer is plugged into an algorithm to calculate the force applied to the transducer.

Load cells are used in several types of measuring instruments such as weighing scales, universal testing machines.

Features: –

Rated load :200KG
Sensitivity :2.0±0.05mV/V
Zero balance : ±1%F.S
TCO : ±0.05%F.S
Input resistance : 350±20Ω
Output resistance : 350±5Ω
Insulation resistance : ≥5000MΩ
Safe overload : 150%F.S
Recommended excitation: 10~15V DC
Operating temperature range : -20~80°C
Cable Color Code :Input: Red(+) Black(-); Output: Green(+) White(-);

200KG Capacity Strain Gauge Specifications: –

Parameter	Value
Type	Single Point Load Cell
Total Precision	C3 class
Material	Aluminum Alloy
Surface	Anodized Treatment
Protection	IP65
Suggested Platform Size	350 x 350 mm
Applications	Weighing Scales, Retail, Bench & Counting Scales
Rated Load	200 Kg. Max
Rated Output	2.0mV/V+/- 5%
Zero Balance	+/- 1% Full Scale
Input Resistance	405 +/- 6 Ohm
Output Resistance	350 +/- 3 Ohm
Excitation Voltage	5-12V DC
Nonlinearity	0.017% Full Scale
Hysteresis	0.02% Full Scale
Repeatability	0.01% Full Scale
Creep(30min)	0.015% Full Scale
Operating Temperature	-20 °C to +65 °C
Temperature Effect on Zero	0.017% Full Scale / 10 °C
Temperature Effect on Span	0.014% Full Scale / 10 °C
Insulation Resistance	5000 Mega Ohm(50V DC)
Safe Overload	150% Full Scale
Ultimate Overload	200% Full Scale
Cable	420mm(3mm dia 4 wire shielding cable)
