Active Buzzer 6V DC Electromagnetic Mini Piezo Buzzer
5v PCB Mount Buzzer is perfect for all types of DIY and breadboard projects as well as actual electronics production. This Buzzer module really loud sound when 3V to 5V is apply to it.
Active Buzzer 6V DC Electromagnetic Mini Piezo Buzzer is a small Buzzer, which can be mount on PCB. It has two pins; the bigger pin should be connected to positive supply and shorter one should be connected to ground connection.
Operating voltage range is 5-12V. If you provide provide square wave of 5V, it will create a good sound. for a optimum sound quality provide 2-4KHz wave
Active Buzzer 6V DC is perfect for all types of DIY and breadboard projects as well as actual electronics production. This Buzzer module really loud sound when 3V to 5V is apply to it.
Unlike a plain piezo, 5v PCB Mount Buzzer does not need an AC signal. Inside is a piezo plus the driver circuitry that makes it oscillate at 2 KHz. On one hand, that makes it really great for integrating into projects because you don’t need an oscillating control signal.
but On the other hand, you cannot change the frequency.
Active Buzzer 6V DC is ideal when you need to fit a buzzer in a small place. Apply 3V to 5V to this piezo buzzer module and you’ll be rewarded with a loud 2KHz BEEP.
5v PCB Mount Buzzer is great to add Audio Alert in your electronic designs
Miniature electromagnetic buzzer with internal oscillator drive circuit for direct PCB mounting. Potted flux-proof base and tear off top label permit board cleaning.
Good performance, general purpose piezo buzzer used commonly in alerting / alarming circuits. 5v PCB Mount Buzzer can be easily soldered to PCB board. Most commonly used in at 5v. Long life, stable performance, High Quality with SOT plastic package
A round PCB mount continuous tone buzzer, with a high sound output and internal circuitry for DC operation.
- ABS external material, DC 3-12V operating voltage, 2 wire, convenient for wiring.
- Decibel: 75DB, continuous sound beep.
- An ideal item for machinery equipment, oven, electric cabinet, industrial using, etc.
Active Buzzer 6V DC Specifications: –
- Color: Black
- Alarm Diameter: 29mm / 1.14″
- Alarm Height: 15mm / 0.59″
- 2 Mounting Holes Distance: 40mm / 1.57″
- 2 Wires length: 105mm / 4.13″
- Rated Voltage: 12V
- Operating Voltage: 3-24V
- Rated Current(MAX): 20mA
- Min Sound Output at 10 cm:
- 95 DB 10. Resonant Frequency: 3100±500
- Operating Temperature:-20~80℃
- Intermittent Sound & Mounting Holes
- DIY Projects
- Security Alarm System.
- Garage, Door safety
Pin Description: –
|1||Positive||Identified by (+) symbol or longer terminal lead. Can be powered by 6V DC|
|2||Negative||Identified by short terminal lead. Typically connected to the ground of the circuit|
1 x Active Buzzer 6V DC
