Arduino UNO Sensor Shield V5 Expansion Board

@ MODERN HALLROAD

The Arduino UNO Sensor Shield V5 Expansion Board fits Uno, Mega 2560 and similar form-factor Arduino boards and provides a convenient way to interface to sensors and other peripherals such as servo motors. The Arduino UNO Sensor Shield V5 Expansion Board comes with an external power connector, helping you get rid of the overloading of the Arduino board while working with too many actuators and sensors.

 250.00

The Arduino UNO Sensor Shield V5 Expansion Board fits Uno, Mega 2560 and similar form-factor Arduino boards and provides a convenient way to interface to sensors and other peripherals such as servo motors. The Arduino UNO Sensor Shield V5 Expansion Board comes with an external power connector, helping you get rid of the overloading of the Arduino board while working with too many actuators and sensors.

The 3-way male pin header is used to connect servo motors with the Arduino Board. This is a plug and play device. You can read data from the sensors connected with the shield and use it to drive servo motors with the Arduino boards.

The Arduino UNO Sensor Shield V5 Expansion Board an easy way to connect sensors, servos and RS485 device to Arduino board. It expands Arduino’s Digital I/O and Analog Input Pins with Power and GND.

It also provides separate PWM Pins which are compatible with standard servo connector. Another unique feature is that the I/O shield has a build-in RS485 converter which allows Arduino communicating with RS485 devices.

The communication socket provides an extremely easy way to plug a wireless module such as APC220 RF module and DF-Bluetooth module. It has an individual power input for Servos. A servo power jumper allows user to select using external power or internal power to drive the Servos.

The latest Arduino Controller Sensor Shield V5.0 is produced by ALSRobot. This Sensor Shield expansion board to retains the advantages of version V4.0 on the basis of stack design, PCB Immersion Gold processing technology. newly added many kind of interface, for example,11C interface, 32 channels servo motor interface, Bluetooth communication module interface, SD Card communication module interface and so on, more convenient.

Features: –

  • This shield brings out the standard Arduino I/O pins to headers along with dedicated ground and power pins per I/O to facilitate connecting sensors other devices.
  • The shield also has a number of dedicated connectors that are defined for specific purposes as outlined below, but they can also be considered as general purpose connection points.
  • An auxiliary power connector allows separate power to be supplied to the power pins associated with the D0-D13 pins which is handy for driving servo motors.
  • A remote reset switch is located on the shield for easy access.  It also brings the on-board pin-13 ‘L’ LED up to the shield for easy visibility.

Arduino UNO Sensor Shield V5 Specifications: –

  • Materials : Plastic, PCB
  • Main Color : Blue, Silver Tone
  • Net Weight : 30g

Arduino UNO Sensor Shield V5 Pin Description: –

  • PIN13 LED Pilot
  • Digital IO Ports D0-D13
  • Analog IO Ports A0-A5
  • Reset Button
  • Power In
  • Power LED
  • SD Card Interface
  • Ultrasonic Interface
  • RS232 Interface(TTL)
  • Bluetooth Interface
  • APC220 Interface
  • IIC Interface
  • 12864 LCD Parallel Interface
  • 12864 LCD Serial Interface
Package: –

1 x Arduino UNO Sensor Shield V5 Expansion Board For Arduino
