Atmel Atmega328p Microcontroller 8 Bit 28 Pins Microcontroller

@ MODERN HALLROAD

IC Atmega 328P or ATmega328P-PU is the same microcontroller chip used on the Arduino Uno boards and comes in a breadboard friendly package.

 1,500.00

In stock

Atmel Atmega328p Microcontroller or ATmega328P-PU is the same microcontroller chip used on the Arduino Uno boards and comes in a breadboard friendly package.

This is a blank chip for do-it-yourselfers who want to program their own microcontrollers from scratch. It comes in a standard 28 pin DIP package that is easy to handle, solder or use on a breadboard.

Atmel Atmega328p Microcontroller is an 8 bit AVR microcontroller with 32K of FLASH, 2K of RAM and 1K of EEPROM memory. In can run at clock speeds up to 20 Mhz and is able to operate at voltages from 1.8V to 5.5V. It has 23 GPIO General Purpose Input and Output lines with alternate functions to provide USART, SPI, I2C, 10 bit ADC, PWM and other features.

This microcontroller does not have a bootloader. You will need a programmer such as an ISP In-System Programming tool to program this chip.

IC Atmega 328P is used similar to any other controller. All there to do is programming. Controller simply executes the program provided by us at any instant. Without programming controller simply stays put without doing anything.

The Atmel 8-bit AVR RISC-based microcontroller combines 32 KB ISP flash memory with read-while-write capabilities, 1 KB EEPROM, 2 KB SRAM, 23 general-purpose I/O lines, 32 general-purpose working registers, 3 flexible timer/counters with compare modes, internal and external interrupts, serial programmable USART, a byte-oriented 2-wire serial interface, SPI serial port, 6-channel 10-bit A/D converter (8 channels in TQFP and QFN/MLF packages), programmable watchdog timer with internal oscillator, and 5 software-selectable power-saving modes. The device operates between 1.8 and 5.5 volts. The device achieves throughput approaching 1 MIPS/MHz.

Features: –

Parameter Value
CPU type 8-bit AVR
Maximum CPU speed 20 MHz
Performance 20 MIPS at 20 MHz[2]
Flash memory 32 KB
SRAM 2 KB
EEPROM 1 KB
Package pin count 28 or 32
Capacitive touch sensing channels 16
Maximum I/O pins 23
External interrupts 2
USB interface No

Atmel Atmega328p Microcontroller Specifications: –

  • Number of Pins: 28
  • Architecture: 8-bit
  • Op Temperature:-40 ~ 85°C
  • Series: ATMega
  • 4.5V-5.5V operating range
  • Up to 20MHz
  • Part: ATMEGA328P-AU
  • 32kB Flash program memory
  • 1kB EEPROM
  • 2kB Internal SRAM
  • Two 8-bit Timer/Counters
  • One 16-bit Timer/Counter
  • RTC with separate oscillator
  • 6 PWM Channels
  • 8 Channel 10-bit ADC
  • Serial USART
  • Master/Slave SPI interface
  • 2-wire (I2C) interface
  • Watchdog timer
  • Analog comparator
  • 23 IO lines
  • Data retention: 20 years at 85oC/ 100 years at 25oC

Atmel Atmega328p Microcontroller Applications: –

  • Used in ARDUINO UNO, ARDUINO NANO and ARDUINO MICRO boards.
  • Industrial control systems.
  • SMPS and Power Regulation systems.
  • Digital data processing.
  • Analog signal measuring and manipulations.
  • Embedded systems like coffee machine, vending machine.
  • Motor control systems.
  • Display units.
  • Peripheral Interface system.
  • Burglar alarm system
  • Smoke and fire alarm system
  • Garage door controllers
  • Car door controllers
  • Car alarm system
  • Security system
  • Cordless telephones
  • Other remote control systems
IC Atmega 328P Datasheet:

ww1.microchip.com/…/Atmel-7810-Automotive-Microcontrollers-ATmega328P_Datasheet.pdf

Package: –

1 x Atmel Atmega328p Microcontroller
