DS18B20 Waterproof Temperature Sensor Probe
- DS18B20 Waterproof Temperature Sensor Probe with Thermal Probe lets you precisely measure temperatures in wet environments with a simple 1-Wire interface.
DS18B20 Waterproof Temperature Sensor with Thermal Probe lets you precisely measure temperatures in wet environments with a simple 1-Wire interface.
The DS18B20 temperature sensor provides 9 to 12-bit temperature readings over a 1-Wire interface, so that only one wire needs to be connected from a central microprocessor.
Dallas DS18B20 One Wire Temperature Sensor is a pre-wired and waterproofed (with heat shrink) version of a 1 Wire DS18B20-compatible sensor.
Handy for when you need to measure something far away, or in wet conditions. While the sensor is good up to 125°C the cable is jacketed in PVC so we suggest keeping it under 100°C.
Because they are digital, you don’t get any signal degradation even over long distances! These 1-wire digital temperature sensors are fairly precise (±0.5°C over much of the range) and can give up to 12 bits of precision from the onboard digital-to-analog converter.
DS18B20 Temperature Sensor Probe work great with any microcontroller using a single digital pin, and you can even connect multiple ones to the same pin, each one has a unique 64-bit ID burned in at the factory to differentiate them. Usable with 3.0-5.0V systems.
Because each DS18B20 Temperature Sensor Probe contains a unique silicon serial number, multiple DS18B20s can exist on the same 1-Wire bus.
This allows for placing temperature sensors in many different places. Applications where this feature is useful include HVAC environmental controls, sensing temperatures inside.
We toss in a 4.7k resistor, which is required as a pullup from the DATA to VCC line when using the sensor.
Dallas DS18B20 One Wire Temperature Sensor an electronic thermometer which has high accuracy over a wide range . You can locate these thermometer chips up to 100M away from your Arduino.
- Unique 1-Wire interface requires only one port pin for communication .
- Converts temperature to 12-bit digital word in 750ms (max.)
- User-definable nonvolatile (NV) alarm settings
- Alarm search command identifies and addresses devices whose temperature is outside of programmed limits (temperature alarm
- Available in 8-pin SO (150mil), 8-pin μSOP, and 3-pin TO-92 packages
- Software compatible with the DS1822
- Applications include thermostatic controls, industrial systems, consumer products, thermometers, or any thermally sensitive
- system One Wire Bus System
- Stainless steel tube 6mm diameter by 30mm long
- Cable is 36″ long / 91cm, 4mm diameter
- Contains DS18B20-compatible temperature sensor
- If your sensor has four wires – Red connects to 3-5V, Black connects to ground and White is data. The copper wire is soldered to the wire shielding
- If your sensor has three wires – Red connects to 3-5V, Blue/Black connects to ground and Yellow/White is data
DS18B20 Waterproof Temperature Sensor Probe Specifications: –
- Usable temperature range: -55 to 125°C (-67°F to +257°F)
- 9 to 12 bit selectable resolution
- Uses 1-Wire interface- requires only one digital pin for communication
- Unique 64 bit ID burned into chip
- Multiple sensors can share one pin
- ±0.5°C Accuracy from -10°C to +85°C
- Temperature-limit alarm system
- Query time is less than 750ms
- Usable with 3.0V to 5.5V power/data
Applications where this feature is useful include HVAC environmental controls, sensing temperatures inside buildings, equipment or machinery, and process monitoring and control.
Supporting Documents: –
- Datasheet (DS18B20)
- Simple Sketch Code
- mbed Example
1 x DS18B20 Waterproof Temperature Sensor Probe
