1088AS MAX7219 8X8 LED Dot Matrix Module LED 2 in 1

The 1088AS MAX7219 8X8 LED Dot Matrix Module LED 2 in 1 is a small electronic module that can be used to display text, images, and animations on an 8X8 LED matrix. Dot Matrix Module uses the MAX7219 LED driver chip, which allows it to be controlled by a microcontroller such as an Arduino.

The module has 3 input pins: DIN (data in), CLK (clock), and CS (chip select). The DIN pin is used to send data to the module, the CLK pin is used to synchronize the data transfer, and the CS pin is used to select the module.

The module also has 8 output pins, one for each LED in the matrix. These pins are connected to the LEDs in common cathode configuration, which means that the LEDs are turned on by applying a low voltage to the output pins.

The MAX7219CWG is a serial input/output common-cathode display driver that interfaces microprocessors (µPs) to 7-segment numeric LED displays of up to 8 digits, bar-graph displays, or 64 individual LEDs. It is a compact, cost-effective, and easy-to-use LED driver chip that can be used in a variety of applications.

The MAX7219CWG dot matrix module is an LED display module that uses the MAX7219 LED driver chip. It has a 8×8 dot matrix with common cathode configuration. The module has 3 input pins: DIN (data in), CLK (clock), and CS (chip select). The DIN pin is use to send data to the module, the CLK pin is use to synchronize the data transfer, and the CS pin is use to select the module.

Features: –

The module also has 8 output pins, one for each LED in the matrix. These pins connected to the LEDs in common cathode configuration, which means that the LEDs are turn on by applying a low voltage to the output pins.

The MAX7219CWG dot matrix module can use to display a variety of information, including text, images, and animations. It can also use to create games, electronic toys, and other interactive applications. Here are some of the features of the MAX7219CWG dot matrix module:

• 8×8 dot matrix with common cathode configuration
• Controlled by the MAX7219 LED driver chip
• 3 input pins: DIN, CLK, and CS
• 8 output pins for the LEDs
• Can use to display text, images, and animations
• Can control by a microcontroller such as an Arduino

1088AS MAX7219 8X8 LED Dot Matrix Module Specifications :-

Here are some of the specifications of the MAX7219CWG:

• Operating voltage: 2.7V to 5.5V
• Current consumption: 20mA
• Number of digits: 8
• LED configuration: Common cathode
• BCD decoder: Yes
• Multiplex scan mode: Yes
• Low-power shutdown mode: Yes
• Analog brightness control: Yes

1088AS MAX7219 8X8 LED Dot Matrix Module Pin Description : –

The 1088AS MAX7219 8X8 Dot Matrix Module LED 2 in 1 can use to display a variety of information, including text, images, and animations. It can also use to create games, electronic toys, and other interactive applications. The MAX7219CWG can connect to a microcontroller using the following connections:

• VCC pin: Connected to the power supply
• GND pin: Connected to ground
• DIN pin: Connected to the data input pin of the microcontroller
• CLK pin: Connected to the clock pin of the microcontroller
• CS pin: Connected to the chip select pin of the microcontroller

1088AS MAX7219 8X8 LED Dot Matrix Module Applications :-

The MAX7219CWG is a popular choice for a variety of applications, including:

• Digital signage
• Electronic displays
• Games
• Electronic toys
• Interactive applications
• Educational projects

Package :-

1x 1088AS MAX7219 8X8 LED Dot Matrix Module
