GY-90615 MLX90615 Sensor Digital IR Infrared Temperature Module

Sold by
sherjaan
@ sherjaan

The GY-90615 MLX90615 is a digital infrared temperature sensor module that uses IR rays to measure the temperature of an object without any physical contact. It communicates to the microcontroller using the I2C protocol.

 2,200.00

In stock

The GY-90615 MLX90615 is a digital infrared temperature sensor module that uses IR rays to measure the temperature of an object without any physical contact. It communicates to the microcontroller using the I2C protocol. The sensor has a temperature range of -70°C to 382.2°C and a resolution of 0.02°C. It is a small, low-cost, and easy-to-use sensor that is ideal for a variety of applications.
The GY-90615 MLX90615 can operate with an input voltage of 2.6V to 3.6V. The recommended input voltage is 3V. The sensor will not operate properly if the input voltage is outside of this range.

The input voltage is important because it determines the accuracy of the temperature measurements. If the input voltage is too low, the sensor will not be able to measure temperatures accurately. If the input voltage is too high, the sensor may be damaged.

GY-90615 Digital IR Infrared Temperature Module is a small, low-cost sensor that can be used to measure the temperature of an object without any physical contact. It uses infrared rays to measure the temperature of the object. The sensor communicates to the microcontroller using the I2C protocol.

The sensor can also measure the temperature of objects up to 50 to 100 cm away. This makes it a versatile sensor that can be used for a variety of applications

The GY-90615 Digital IR Infrared Temperature Module is a popular sensor among hobbyists and makers. It is available for purchase online and in many electronics stores.

To use the GY-90615 Digital IR Infrared Temperature Module, you will need to connect it to a microcontroller. The sensor has a 4-pin interface that is compatible with the I2C protocol. Once the sensor is connected, you can use the microcontroller to read the temperature measurements.

Features : –

GY-90615 MLX90615 Sensor module working principle is to read the temperature of the infrared data through the microcontroller serial port (TTL level) communication output. Serial port baud rate 9600bps and 115200bps have continuous output and query output in two ways, can adapt to different working environment, and all devices connected to the computer.

Here are some of the benefits of the GY-90615 Digital IR Infrared Temperature Module:

  • Small size and low cost
  • Non-contact temperature measurement
  • High accuracy and resolution
  • Easy to use
  • Versatile
  • Long range
  • Fast response time
  • Durable

GY-90615 MLX90615 Sensor Specifications : –

This GY-90615 MLX90615 Sensor module communicates with Arduino using SMBus,up to 127 sensors can be read via common 2 wires. Thanks to the module’s low noise amplifier, 16-bit ADC and powerful DSP unit, it can achieved a high accuracy of 1℃ over wide temperature rage and a high measurement resolution of 0.02℃. here are the specifications of the GY-90615 Digital IR Infrared Temperature Module:

  • Temperature range: -70°C to 382.2°C
  • Resolution: 0.02°C
  • Communication protocol: I2C
  • Input voltage: 2.6V to 3.6V
  • Current draw: 5mA
  • Dimensions: 10.5mm x 13mm x 9.6mm

GY-90615 MLX90615 Sensor Pin Descriptions : –

The GY-90615 Digital IR Infrared Temperature Module has 4 pins:

  • VCC: This pin provides the sensor with power. The recommended voltage is 3V.
  • GND: This pin is the ground pin.
  • SDA: This pin is the serial data pin. It is use to communicate with the sensor using the I2C protocol.
  • SCL: This pin is the serial clock pin. It is use to synchronize the data transfer between the sensor and the microcontroller.
GY-90615 MLX90615 Sensor Applications : –

The GY-90615 Digital IR Infrared Temperature Module is a versatile sensor that can use for a variety of applications. Some of the most common applications include:

  • Thermography
  • HVAC control
  • Industrial process monitoring
  • Medical diagnostics
  • Smart home automation

If you are looking for a small, low-cost, and easy-to-use sensor to measure the temperature of an object, then the GY-90615 Digital IR Infrared Temperature Module is a great option.

Package : –

1 x GY-90615 MLX90615 Sensor
