74LS30 8-Inputs NAND Gate IC

74LS30 is an 8-input NAND gate IC. It is a member of the 74LS family of logic gates, which are based on low power Schottky (LS) technology.

74LS30 has a single output and eight inputs. The output is low (0 volts) if any of the inputs are high (5 volts). The output is high (5 volts) if all of the inputs are low (0 volts).

The 74LS30 is a versatile logic gate that can use in a variety of applications. It can use to perform logical operations such as AND, OR, and NOT. It can also use to create more complex logic circuits.

This device contains a single gate which performs the logic NAND function. A NAND Gate is a logical gate which is a combination of AND and NOT gates. It is considered as a “universal” gate in Boolean algebra as it is capable of producing all other logic gates.

74LS30 IC package contains two independent positive logic 8-input NAND Gates. It is the part of 74XXYY IC series.

74LS30 IC has a wide range of working voltage, a wide range of working conditions, and directly interfaces with CMOS, NMOS, and TTL. The output of the IC always comes in TTL which makes it easy to work with other TTL devices and microcontrollers.

IC 74LS30 is smaller in size and it has a much faster speed which makes it reliable in every kind of device.

Features : –

74LS30 NAND Gate is a logical gate which is a combination of AND and NOT gates. It is considered as a “universal” gate in Boolean algebra as it is capable of producing all other logic gates.

• Single NAND Gate with 8 Inputs
• Wide Operating Voltage
• Operating Temperature up to 70°C
• Standard DIP 74LS30 IC

74LS30 8-Inputs NAND Gate IC Specifications : –

74LS30 is a reliable and easy-to-use logic gate that is well-suited for a variety of applications. It is a popular choice for hobbyists and engineers alike.

Here are some of the features of the 74LS30 8-input NAND gate IC:

• 8-input NAND gate
• Low-power Schottky (LS) technology
• Single output
• Wide operating voltage range (4.75 to 5.25 volts)
• TTL outputs
• Low power consumption
• Fast switching speed
• Wide operating temperature range (0 to 70 degrees Celsius)
• Durable and reliable

74LS30 8-Inputs NAND Gate IC Applications : –

74LS30 8-input NAND gate IC can use in a variety of applications, including:

• Digital logic circuits
• Programmable logic controllers (PLCs)
• Computer systems
• Telecommunications equipment
• Industrial control systems
• Consumer electronics
• And many more!

Package : –

1 x 74LS30 8-Inputs NAND Gate IC
