470UF 16V Capacitor Aluminum Electrolytic Polar Capacitor

This 470uF 16V capacitor is an electrolytic capacitor with a capacitance of 470 microfarads and a voltage rating of 16 volts. 16V 470uF capacitor is a polarized capacitor, which means that it has a positive and a negative lead. The positive lead is longer than the negative lead. Electrolytic capacitors are typically use to store charge and filter noise in electronic circuits.

The voltage rating of a capacitor is the maximum voltage that it can withstand without breaking down. A 470uF 16V capacitor has a voltage rating of 16 volts. This means that the capacitor can withstand a voltage of up to 16 volts without breaking down. If the capacitor is exposed to a voltage that is higher than 16 volts, it will likely break down and stop working.

A 470uF 16V capacitor is an electrolytic capacitor. Electrolytic capacitors work by using a dielectric material, such as aluminum oxide, to separate two conductive plates. The plates are then charged with opposite polarity, with the positive plate connected to the positive lead of the capacitor and the negative plate connected to the negative lead.

When a voltage is applied to the capacitor, the dielectric material allows electrons to flow from the positive plate to the negative plate. This creates a charge on the capacitor. The amount of charge that is stored on the capacitor is proportional to the voltage that is applied to it.

When the voltage is remove from the capacitor, the electrons flow back from the negative plate to the positive plate. This discharges the capacitor.

Electrolytic capacitors are typically used to store charge and filter noise in electronic circuits. They can also use to create timing circuits and to generate pulses of current.

Features: –

Here are some of the benefits of using a 470uF 16V capacitor

• Stores charge
• Filters noise
• Provides voltage stability
• Provides transient protection
• Low cost

470UF 16V Capacitor Specifications : –

• Capacitance: 470 microfarads
• Voltage rating: 16 volts
• Tolerance: ±20%
• ESR: 10 milliohms
• Temperature range: -40°C to +85°C
• Life expectancy: 10,000 hours

470UF 16V Capacitor Applications: –

Here are some of the common applications of a 470uF 16V capacitor:

• Power supply filtering: Electrolytic capacitors are often use in power supplies to filter out noise and ripple from the input voltage. This helps to ensure that the output voltage is clean and stable.
• Audio coupling: Electrolytic capacitors are also use to couple audio signals between different stages of an amplifier. This helps to prevent the signals from being distorted.
• Charge storage: Electrolytic capacitors can use to store charge for later use. This is useful in circuits that need to provide a sudden burst of current, such as a camera flash.
• Decoupling: Electrolytic capacitors can use to decouple different parts of a circuit. This helps to prevent noise from one part of the circuit from affecting another part.

Package : –

1 x 470UF 16V Capacitor Aluminum Electrolytic Polar Capacitor
