Name: 74LS01 Quad 2-Inputs NAND Gate IC
SKU: 13290
Price: 30.00 PKR
Availability: OutOfStock

74LS01 Quad 2-Inputs NAND Gate IC can use to perform a variety of logic operations, such as AND, OR, NOT, and XOR. It can also use to create counters, flip-flops, and other sequential circuits. 74LS01 is a versatile and widely used IC. It is an essential building block for many electronic systems.

74LS01 is a quad 2 input NAND gate IC. It is a low power Schottky (LS) version of the 7401, which was the first commercial integrated circuit. In digital electronics, a NAND gate is a logic gate which produces an output which is false only if all its inputs are true; thus its output is complement to that of an AND gate.

The 74LS01 has four independent NAND gates. Each gate has two inputs and one output. The output of a NAND gate is low (0 V) when both inputs are high (1 V). The output is high (1 V) when either input is low (0 V)

It achieves a high−speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation almost like LS-TTL gates. In this IC, the open collector outputs require pull−up resistors to function correctly. They may be connected to other open-collector outputs to implement active−low wired−OR or active−high wired−AND functions. Open collector devices often used to generate higher VOH levels.

74LS01 designed as a high speed Quad 2 Input Positive NAND gate IC fabricated in low power schotkey technology. These devices come with four independent 2-input Positive-NAND gates. They perform the Boolean functions Y = A • B or Y = A + B in positive logic.

Features : –

74LS01 designed as an advanced high-speed CMOS 2 Input NAND circuit fabricated with silicon gate CMOS technology.

Here are some key features of 74LS01

Four Independent NAND Gates
Standard Pin Configuration
Also Available in SMD Type
Operating Temperature to 70°C
Standard TTL Switching Voltages

74LS01 Quad 2-Inputs NAND Gate IC Specifications : –

The NAND gate is a type of digital logic gate that is frequently utilised in DLD applications. It’s also known as a universal logic gate since it can use to implement any logic gate or expression known to man. If any of the NAND gate’s inputs are set to high, the gate’s output will always be a logical low. A NAND gate, on the other hand, produces a logical high only when all of its inputs are set to LOW.

Here are below some key specifications of 74LS01

Quad 2-Input NAND Gate
No. of gates: 4
High-level input voltage: 2V
Low-level input voltage: 0.8V
High-level output voltage: 5.5V
Low-level output current: 8mA
Input clamp voltage: -1.5V
No of inputs: 8
No. of outputs: 4

74LS01 Quad 2-Inputs NAND Gate IC Applications : –

74LS01 is a reliable and versatile IC that can use in a wide variety of applications. It is an essential building block for many electronic systems.

Here are some of the applications of the 74LS01:

Logic gates: The 74LS01 can use to create a variety of logic gates, such as AND, OR, NOT, and XOR.
Counters: The 74LS01 can use to create counters, which are devices that count the number of times an event has occurred.
Flip-flops: The 74LS01 can use to create flip-flops, which are devices that store a single bit of data.
Sequential circuits: The 74LS01 can use to create sequential circuits, which are circuits that change their state over time.
