74LS09 Quad 2-Input AND Gate Open Collector

74LS09 is a quad 2-input AND gate integrated circuit (IC) with open collector outputs. It is a member of the 74LS00 series of low-power Schottky TTL logic ICs. The 74LS09 has four independent AND gates, each with two inputs and one open collector output.

The open collector outputs allow the 74LS09 to be used in a variety of applications, such as wired-OR and wired-AND logic, and to drive LEDs, motors, and other loads.

This device contains four independent gates each of which performs the logic AND function. The open-collector outputs require external pull-up resistors for proper logical operation.

74LS09 is a quad 2-input AND gate integrated circuit (IC) that is used in digital logic circuits. It is a member of the 74LS00 series of low-power Schottky TTL logic ICs. The 74LS09 has four independent AND gates, each with two inputs and one output. The inputs of the 74LS09 are compatible with standard TTL logic, while the outputs are compatible with LSTTL logic.

The 74LS09 can be used in a variety of applications, including digital logic circuits, control circuits, and data acquisition systems.

The open-collector outputs require pull-up resistors to perform correctly. They may be connected to other open-collector outputs to implement active-low wired-OR or active-high wired-AND functions. Open-collector devices are often used to generate higher VOH levels.

74LS09 works by performing the AND operation on the two inputs of each gate. The output of each gate will be high only if both inputs are high. The outputs of the 74LS09 are buffered, which means that they can drive a higher current than the inputs. This makes the 74LS09 suitable for driving LEDs, motors, and other loads.

Features : –

Here are some of the key features of the 74LS09:

• Low power consumption: The 74LS09 consumes very little power, making it ideal for battery-operated applications.
• High speed: The 74LS09 operates at speeds up to 30 MHz, which makes it suitable for use in high-speed digital circuits.
• Wide operating temperature range: The 74LS09 can operate in a wide temperature range of -55°C to +125°C, making it suitable for use in a variety of environments.

74LS09 Quad 2-Input AND Gate Specifications : –

Here are some of the key Specifications of the 74LS09:

74LS09 Quad 2-Input AND Gate Applications : –

74LS09 is a versatile and powerful IC that can be used in a wide variety of applications. It is a reliable and cost-effective choice for designers of digital circuits.

Here are some of the applications of the 74LS09:

• Digital logic circuits
• Control circuits
• Data acquisition systems
• Programmable logic controllers (PLCs)
• Microcontroller systems
• Robotics
• Industrial automation
• Consumer electronics

Package : –

1 x 74LS09 Quad 2-Input AND Gate Open Collector
