74LS11 Triple 3-Input Positive AND Gate

74LS11 is a triple 3 input positive AND gate integrated circuit (IC) in the 74xx family of logic ICs. It has three independent 3-input AND gates, each of which performs the logic AND function. The input voltage is 7V, the maximum supply voltage is 7V, and the maximum current allowed to draw through each gate output is 8mA.

The outputs are TTL, which makes it easy to work with other TTL devices and microcontrollers. The 74LS11 has a low power consumption, typical rise time of 18ns, typical fall time of 18ns, and operating temperature of 0°C to +70°C.

74011 IC usually use in a place where 3 – input logical AND operation is required. Also used in devices such as PCs and notebooks. This device contains three independent gates each of which performs the logic AND function.

74LS11 is a triple 3-input AND gate IC. This means that it has three independent 3-input AND gates. An AND gate is a logic gate that produces a logic 1 output only when all of its inputs are logic 1. The 74LS11 has a low power consumption, high speed, and wide operating temperature range. It is a TTL (Transistor-Transistor Logic) IC, which means that it is compatible with other TTL devices.

The 74LS11 can be used in a variety of applications, such as digital logic circuits, programmable logic controllers (PLCs), microcontrollers, data acquisition systems, test and measurement equipment, industrial control systems, and consumer electronics.

Features : –

74LS11 Triple 3-Input AND Gate IC can be soldered directly to the circuit board or can be mounted on a 14 pin IC base. 74LS11 Triple 3-Input AND Gate circuit is designed such that the AND operation of the input pins 1,2 & 13, 3, 4&5, 9,10 & 11 are produced on the pin 12,6& 8 respectively.

Here are some of the features of the 74LS11:

• Triple 3-input positive AND gate
• TTL (Transistor-Transistor Logic) IC
• Low power consumption
• High speed
• Wide operating temperature range
• Compatible with other TTL devices
• Wide range of applications

74LS11 Triple 3-Input Positive AND Gate Specifications : –

The 74LS11 Triple 3-Input AND Gatecontains three independent gates each of which performs the logic AND function. 74LS11 Triple 3-Input AND Gate IC can be soldered directly to the circuit board or can be mounted on a 14 pin IC base.

• Standard Pin Configuration
• Operating Voltage Range 4.75V to 5V up to a maximum of5.5V.
• Operating Temperature range : -55°C to +125°C.
• VH (Output High): 2.7V to 3.4V.
• VL (Output Low): 0.36V to 0.5V.
• Power Consumption: 4.8mA to 8.8mA.
• Operating Speed (Mhz):125 – 250.

74LS11 Triple 3-Input Positive AND Gate Applications : –

The 74LS11 is a versatile and reliable IC that can use in a wide range of applications. It is a popular choice for engineers and hobbyists alike.

Here are some of the applications of the 74LS11:

• Digital logic circuits
• Programmable logic controllers (PLCs)
• Microcontrollers
• Data acquisition systems
• Test and measurement equipment
• Industrial control systems
• Consumer electronics

Package

1 x 74LS11 Triple 3-Input Positive AND Gate
